Import Remote Assets - Android

package ly.img.editor.showcase

import android.net.Uri
import ly.img.engine.DesignBlock
import ly.img.engine.DesignBlockType
import ly.img.engine.Engine
import ly.img.engine.FillType
import ly.img.engine.FindAssetsQuery
import ly.img.engine.MimeType

data class RemoteAsset(
    val remoteSourceId: String,
    val stringSourceId: String,
    val hostedSourceId: String,
    val remoteAssetLoaded: Boolean,
    val stringAssetCount: Int,
    val appliedBlock: DesignBlock?,
    val appliedBlockType: String?,
    val registeredSources: List<String>,
    val hostedSourceRemoved: Boolean,
    val invalidJsonRejected: Boolean,
)

suspend fun remoteAsset(
    engine: Engine,
    assetBaseUri: Uri,
): RemoteAsset {
    listOf("my.remote.images.uri", "my.remote.images", "my.remote.images.hosted").forEach { sourceId ->
        if (sourceId in engine.asset.findAllSources()) {
            engine.asset.removeSource(sourceId = sourceId)
        }
    }

    val scene = engine.scene.create()
    val page = engine.block.create(DesignBlockType.Page)
    engine.block.setWidth(page, value = 800F)
    engine.block.setHeight(page, value = 600F)
    engine.block.appendChild(parent = scene, child = page)

    val remoteAssetsBaseUri = assetBaseUri
    val imageManifestUri = remoteAssetsBaseUri.buildUpon()
        .appendPath("my.remote.images.uri")
        .appendPath("content.json")
        .build()

    val sampleImageUri = remoteAssetsBaseUri.buildUpon()
        .appendPath("imgly-assets")
        .appendPath("ly.img.image")
        .appendPath("images")
        .appendPath("sample_1.jpg")
        .build()

    val imageSourceId = engine.asset.addLocalSourceFromJSON(
        contentUri = imageManifestUri,
        matcher = listOf("sample_1"),
    )

    val manifestJSON = """
        {
          "version": "2.0.0",
          "id": "my.remote.images",
          "assets": [
            {
              "id": "sample_image",
              "label": { "en": "Sample Image" },
              "meta": {
                "uri": "$sampleImageUri",
                "thumbUri": "$sampleImageUri",
                "kind": "image",
                "fillType": "${FillType.Image.key}",
                "mimeType": "${MimeType.JPEG.key}",
                "width": 2500,
                "height": 1667
              }
            }
          ]
        }
    """.trimIndent()
    val stringSourceId = engine.asset.addLocalSourceFromJSON(
        contentJSON = manifestJSON,
        basePath = null,
        matcher = null,
    )

    val hostedManifestJSON = """
        {
          "version": "2.0.0",
          "id": "my.remote.images.hosted",
          "assets": [
            {
              "id": "hosted_sample_image",
              "label": { "en": "Hosted Sample Image" },
              "meta": {
                "uri": "{{base_url}}/imgly-assets/ly.img.image/images/sample_1.jpg",
                "thumbUri": "{{base_url}}/imgly-assets/ly.img.image/images/sample_1.jpg",
                "kind": "image",
                "fillType": "${FillType.Image.key}",
                "mimeType": "${MimeType.JPEG.key}",
                "width": 2500,
                "height": 1667
              }
            }
          ]
        }
    """.trimIndent()
    val hostedSourceId = engine.asset.addLocalSourceFromJSON(
        contentJSON = hostedManifestJSON,
        basePath = remoteAssetsBaseUri.toString(),
        matcher = null,
    )

    val remoteAssets = engine.asset.findAssets(
        sourceId = imageSourceId,
        query = FindAssetsQuery(page = 0, perPage = 10),
    )
    val remoteAsset = engine.asset.fetchAsset(
        sourceId = imageSourceId,
        assetId = "sample_1",
    )
    val stringAssets = engine.asset.findAssets(
        sourceId = stringSourceId,
        query = FindAssetsQuery(page = 0, perPage = 10),
    )
    check(remoteAssets.total > 0)

    val hostedAssets = engine.asset.findAssets(
        sourceId = hostedSourceId,
        query = FindAssetsQuery(page = 0, perPage = 10),
    )
    val appliedBlock = hostedAssets.assets.firstOrNull()?.let { asset ->
        engine.asset.defaultApplyAsset(asset = asset)
    }

    val registeredSources = engine.asset.findAllSources()

    engine.asset.removeSource(sourceId = hostedSourceId)

    val invalidJsonRejected = try {
        engine.asset.addLocalSourceFromJSON(
            contentJSON = "{ not valid json }",
            basePath = null,
            matcher = null,
        )
        false
    } catch (_: Exception) {
        true
    }

    return RemoteAsset(
        remoteSourceId = imageSourceId,
        stringSourceId = stringSourceId,
        hostedSourceId = hostedSourceId,
        remoteAssetLoaded = remoteAsset != null,
        stringAssetCount = stringAssets.assets.size,
        appliedBlock = appliedBlock,
        appliedBlockType = appliedBlock?.let(engine.block::getType),
        registeredSources = registeredSources,
        hostedSourceRemoved = hostedSourceId !in engine.asset.findAllSources(),
        invalidJsonRejected = invalidJsonRejected,
    )
}

Load asset definitions from remote JSON files hosted on a CDN or server into CE.SDK’s asset library.

Remote image asset loaded into CE.SDK on Android

8 mins

estimated time

GitHub

Remote asset loading lets you host asset definitions outside your Android app and register them at runtime. This keeps asset management separate from your app release cycle, while the asset metadata still flows through the standard CE.SDK asset APIs.

This guide covers how to load remote asset manifests, load JSON content that you already have in memory, resolve {{base_url}} placeholders, query the loaded assets, and apply them to a scene.

Setup#

Create a scene and a page before applying image assets. The remote asset APIs only register asset data; applying an image later needs an active scene.

val scene = engine.scene.create()
val page = engine.block.create(DesignBlockType.Page)
engine.block.setWidth(page, value = 800F)
engine.block.setHeight(page, value = 600F)
engine.block.appendChild(parent = scene, child = page)

JSON Manifest Structure#

A manifest declares a version, an asset source id, and an assets array. Each asset has an id, localized labels, and a meta object with the URIs and apply hints that CE.SDK needs when the asset is applied.

{
  "version": "2.0.0",
  "id": "my.remote.images.uri",
  "assets": [
    {
      "id": "sample_1",
      "label": { "en": "Sample Image" },
      "meta": {
        "uri": "{{base_url}}/my.remote.images.uri/images/sample.jpg",
        "thumbUri": "{{base_url}}/my.remote.images.uri/thumbnails/sample.jpg",
        "kind": "image",
        "fillType": "//ly.img.ubq/fill/image",
        "mimeType": "image/jpeg",
        "width": 2500,
        "height": 1667
      }
    }
  ]
}

The manifest id becomes the source ID for later calls. uri points to the media file, thumbUri points to a preview image, and the media metadata tells CE.SDK how to apply the asset.

When you load a manifest from <assetBaseUri>/<sourceId>/content.json, {{base_url}} resolves to the asset root, <assetBaseUri>/. Include the source folder in placeholder-based media paths, such as {{base_url}}/my.remote.images.uri/images/sample.jpg.

Loading Assets From a Remote URL#

Build the manifest and media URIs from the root folder that hosts your asset sources. In production, provide your own HTTPS server or CDN root, for example Uri.parse("https://cdn.example.com/cesdk-assets").

val remoteAssetsBaseUri = assetBaseUri
val imageManifestUri = remoteAssetsBaseUri.buildUpon()
    .appendPath("my.remote.images.uri")
    .appendPath("content.json")
    .build()

val sampleImageUri = remoteAssetsBaseUri.buildUpon()
    .appendPath("imgly-assets")
    .appendPath("ly.img.image")
    .appendPath("images")
    .appendPath("sample_1.jpg")
    .build()

Pass the manifest URI to engine.asset.addLocalSourceFromJSON(). The method fetches the JSON, creates a local asset source, and returns the manifest’s source ID. Use source IDs your app owns, and remove or reload those sources intentionally when their manifest changes. Android also accepts an optional matcher list so you can load only asset IDs that match specific strings or wildcard patterns.

val imageSourceId = engine.asset.addLocalSourceFromJSON(
    contentUri = imageManifestUri,
    matcher = listOf("sample_1"),
)

When the URI-loaded manifest uses {{base_url}}, CE.SDK resolves it against the asset root that contains the source folders. For a manifest at https://cdn.example.com/cesdk-assets/my.remote.images.uri/content.json, a media path such as {{base_url}}/my.remote.images.uri/images/sample_1.jpg resolves to https://cdn.example.com/cesdk-assets/my.remote.images.uri/images/sample_1.jpg.

Loading Assets From a JSON String#

Use the string overload when your app already has the manifest content, for example from an API response or embedded configuration. If the manifest contains absolute URLs, you can leave basePath as null.

val manifestJSON = """
    {
      "version": "2.0.0",
      "id": "my.remote.images",
      "assets": [
        {
          "id": "sample_image",
          "label": { "en": "Sample Image" },
          "meta": {
            "uri": "$sampleImageUri",
            "thumbUri": "$sampleImageUri",
            "kind": "image",
            "fillType": "${FillType.Image.key}",
            "mimeType": "${MimeType.JPEG.key}",
            "width": 2500,
            "height": 1667
          }
        }
      ]
    }
""".trimIndent()
val stringSourceId = engine.asset.addLocalSourceFromJSON(
    contentJSON = manifestJSON,
    basePath = null,
    matcher = null,
)

Customizing the Base Path#

When a string manifest contains {{base_url}} placeholders, pass basePath to define the hosting location for relative asset files.

val hostedManifestJSON = """
    {
      "version": "2.0.0",
      "id": "my.remote.images.hosted",
      "assets": [
        {
          "id": "hosted_sample_image",
          "label": { "en": "Hosted Sample Image" },
          "meta": {
            "uri": "{{base_url}}/imgly-assets/ly.img.image/images/sample_1.jpg",
            "thumbUri": "{{base_url}}/imgly-assets/ly.img.image/images/sample_1.jpg",
            "kind": "image",
            "fillType": "${FillType.Image.key}",
            "mimeType": "${MimeType.JPEG.key}",
            "width": 2500,
            "height": 1667
          }
        }
      ]
    }
""".trimIndent()
val hostedSourceId = engine.asset.addLocalSourceFromJSON(
    contentJSON = hostedManifestJSON,
    basePath = remoteAssetsBaseUri.toString(),
    matcher = null,
)

Use this pattern when your backend returns a manifest separately from the CDN or server path that hosts the referenced media.

Verifying Loaded Assets#

Query a source with engine.asset.findAssets() to inspect loaded assets, and fetch a known asset ID to confirm the manifest entry is available. Android uses zero-based pages, so the first page is page = 0.

val remoteAssets = engine.asset.findAssets(
    sourceId = imageSourceId,
    query = FindAssetsQuery(page = 0, perPage = 10),
)
val remoteAsset = engine.asset.fetchAsset(
    sourceId = imageSourceId,
    assetId = "sample_1",
)
val stringAssets = engine.asset.findAssets(
    sourceId = stringSourceId,
    query = FindAssetsQuery(page = 0, perPage = 10),
)

Applying Remote Assets#

Use engine.asset.defaultApplyAsset() to turn a queried asset into a block in the active scene. CE.SDK reads the asset’s meta fields and downloads the referenced media when the block needs it.

val hostedAssets = engine.asset.findAssets(
    sourceId = hostedSourceId,
    query = FindAssetsQuery(page = 0, perPage = 10),
)
val appliedBlock = hostedAssets.assets.firstOrNull()?.let { asset ->
    engine.asset.defaultApplyAsset(asset = asset)
}

If you need custom apply behavior, use a custom AssetSource instead. JSON-backed local sources are a good fit when the manifest metadata already describes how the asset should become a block.

Listing Asset Sources#

Call engine.asset.findAllSources() to inspect the currently registered source IDs.

val registeredSources = engine.asset.findAllSources()

Removing Asset Sources#

Remove a source when your app no longer needs its assets or before reloading the same manifest ID with updated content.

engine.asset.removeSource(sourceId = hostedSourceId)

Error Handling#

Wrap manifest loading in try/catch so your app can handle network errors, missing files, or invalid JSON.

val invalidJsonRejected = try {
    engine.asset.addLocalSourceFromJSON(
        contentJSON = "{ not valid json }",
        basePath = null,
        matcher = null,
    )
    false
} catch (_: Exception) {
    true
}

Common issues include:

Network failures: Check connectivity and whether the manifest URL is reachable from the device.
Invalid JSON: Confirm the manifest contains a version, an id, and an assets array.
Base path issues: Make sure {{base_url}} resolves to reachable media and thumbnail URLs.
Source ID conflicts: Use source IDs your app owns, and avoid removing built-in sources such as ly.img.image.

API Reference#

Method	Description
`engine.scene.create()`	Create the scene that receives applied assets.
`engine.block.create(blockType=DesignBlockType.Page)`	Create a page for the scene.
`engine.block.setWidth(block=_, value=_)`	Set the page width.
`engine.block.setHeight(block=_, value=_)`	Set the page height.
`engine.block.appendChild(parent=_, child=_)`	Add the page to the scene.
`Uri.buildUpon()`	Build manifest and media URIs from a remote asset base URI.
`engine.asset.addLocalSourceFromJSON(contentUri=_, matcher=_)`	Load an asset source from a JSON file URI, optionally filtering asset IDs.
`engine.asset.addLocalSourceFromJSON(contentJSON=_, basePath=_, matcher=_)`	Load an asset source from JSON content, optionally resolving `{{base_url}}` with `basePath`.
`engine.asset.findAssets(sourceId=_, query=_)`	Query assets from a loaded source.
`engine.asset.fetchAsset(sourceId=_, assetId=_)`	Fetch a specific loaded asset by ID.
`engine.asset.defaultApplyAsset(asset=_)`	Apply an asset to the active scene using its metadata.
`engine.asset.findAllSources()`	List registered asset source IDs.
`engine.asset.removeSource(sourceId=_)`	Remove an asset source and its loaded assets.
