Text Decorations - SvelteKit

Add underline, strikethrough, and overline decorations to text blocks with configurable styles, colors, and thickness.

Text decorations demonstration showing underline, strikethrough, and overline styles

5 mins

estimated time

CE.SDK supports three types of text decorations: underline, strikethrough, and overline. We can toggle decorations on and off, customize them with different line styles, and apply them to specific character ranges. All active decoration lines share the same style and thickness settings.

import type { EditorPlugin,EditorPluginContext } from "@cesdk/cesdk-js";

import {
BlurAssetSource,
ColorPaletteAssetSource,
CropPresetsAssetSource,
DemoAssetSources,
EffectsAssetSource,
FiltersAssetSource,
PagePresetsAssetSource,
StickerAssetSource,
TextAssetSource,
TextComponentAssetSource,
TypefaceAssetSource,
UploadAssetSources,
VectorShapeAssetSource
} from '@cesdk/cesdk-js/plugins';
import { DesignEditorConfig } from './design-editor/plugin';
import packageJson from "./package.json";

/**
 * CE.SDK Plugin: Text Decorations Guide
 *
 * Demonstrates text decoration capabilities:
 * - Toggling underline, strikethrough, and overline
 * - Querying current decorations
 * - Setting custom decoration styles, colors, and thickness
 * - Applying decorations to character ranges
 * - Combining multiple decoration types
 */
class Example implements EditorPlugin {
  name = packageJson.name;

  version = packageJson.version;

  async initialize({ cesdk }: EditorPluginContext): Promise<void> {
    if (!cesdk) {
      throw new Error("CE.SDK instance is required for this plugin");
    }

    await cesdk.addPlugin(new DesignEditorConfig());

    // Add asset source plugins
    await cesdk.addPlugin(new BlurAssetSource());
    await cesdk.addPlugin(new ColorPaletteAssetSource());
    await cesdk.addPlugin(new CropPresetsAssetSource());
    await cesdk.addPlugin(
      new UploadAssetSources({ include: ["ly.img.image.upload"] })
    );
    await cesdk.addPlugin(
      new DemoAssetSources({
        include: [
          "ly.img.templates.blank.*",
          "ly.img.templates.presentation.*",
          "ly.img.templates.print.*",
          "ly.img.templates.social.*",
          "ly.img.image.*",
        ],
      })
    );
    await cesdk.addPlugin(new EffectsAssetSource());
    await cesdk.addPlugin(new FiltersAssetSource());
    await cesdk.addPlugin(new PagePresetsAssetSource());
    await cesdk.addPlugin(new StickerAssetSource());
    await cesdk.addPlugin(new TextAssetSource());
    await cesdk.addPlugin(new TextComponentAssetSource());
    await cesdk.addPlugin(new TypefaceAssetSource());
    await cesdk.addPlugin(new VectorShapeAssetSource());

    await cesdk.actions.run("scene.create", {
      page: { width: 800, height: 600, unit: "Pixel" },
    });

    const engine = cesdk.engine;
    const page = engine.block.findByType("page")[0];


    // Create a text block to demonstrate decorations
    const text = engine.block.create("text");
    engine.block.appendChild(page, text);
    engine.block.setPositionX(text, 100);
    engine.block.setPositionY(text, 100);
    engine.block.setWidthMode(text, "Auto");
    engine.block.setHeightMode(text, "Auto");
    engine.block.replaceText(text, "Hello CE.SDK");

    // Toggle underline on the entire text
    engine.block.toggleTextDecorationUnderline(text);

    // Toggle strikethrough on the entire text
    engine.block.toggleTextDecorationStrikethrough(text);

    // Toggle overline on the entire text
    engine.block.toggleTextDecorationOverline(text);

    // Calling toggle again removes the decoration
    engine.block.toggleTextDecorationOverline(text);
    // Query the current decoration configurations
    // Returns a list of unique TextDecorationConfig objects in the range
    const decorations = engine.block.getTextDecorations(text);
    // Each config contains: lines, style, underlineColor, underlineThickness, underlineOffset, skipInk

    // Set a specific decoration style
    // Available styles: 'Solid', 'Double', 'Dotted', 'Dashed', 'Wavy'
    engine.block.setTextDecoration(text, {
      lines: ["Underline"],
      style: "Dashed",
    });

    // Set a custom underline color (only applies to underlines)
    // Strikethrough and overline always use the text color
    engine.block.setTextDecoration(text, {
      lines: ["Underline"],
      underlineColor: { r: 1, g: 0, b: 0, a: 1 },
    });

    // Adjust the underline thickness
    // Default is 1.0, values above 1.0 make the line thicker
    engine.block.setTextDecoration(text, {
      lines: ["Underline"],
      underlineThickness: 2.0,
    });

    // Adjust the underline position relative to the font default
    // 0 = font default, positive values move further from baseline, negative values move closer
    engine.block.setTextDecoration(text, {
      lines: ["Underline"],
      underlineOffset: 0.1,
    });

    // Apply decorations to a specific character range using UTF-16 indices
    // Toggle underline on characters 0-5 ("Hello")
    engine.block.toggleTextDecorationUnderline(text, 0, 5);

    // Set strikethrough on characters 6-12 ("CE.SDK")
    engine.block.setTextDecoration(text, { lines: ["Strikethrough"] }, 6, 12);

    // Query decorations in a specific range
    const subrangeDecorations = engine.block.getTextDecorations(text, 0, 5);

    // Combine multiple decoration lines on the same text
    // All active lines share the same style and thickness
    engine.block.setTextDecoration(text, {
      lines: ["Underline", "Strikethrough"],
      style: "Solid",
    });

    // Remove all decorations
    engine.block.setTextDecoration(text, { lines: ["None"] });

    // Select the text block to show it in the inspector
    engine.block.setSelected(text, true);

    // Suppress unused variable warnings
    void decorations;
    void subrangeDecorations;
  }
}

export default Example;

This guide covers toggling decorations, querying current state, setting custom styles, adjusting color and thickness, and applying decorations to character subranges.

Toggle Decorations#

We toggle decorations using engine.block.toggleTextDecorationUnderline(), engine.block.toggleTextDecorationStrikethrough(), and engine.block.toggleTextDecorationOverline(). If all characters in the range already have the decoration, it is removed; otherwise, it is added to all.

// Toggle underline on the entire text
engine.block.toggleTextDecorationUnderline(text);

// Toggle strikethrough on the entire text
engine.block.toggleTextDecorationStrikethrough(text);

// Toggle overline on the entire text
engine.block.toggleTextDecorationOverline(text);

// Calling toggle again removes the decoration
engine.block.toggleTextDecorationOverline(text);

Query Decorations#

We query the current decorations using engine.block.getTextDecorations(). It returns an ordered list of unique TextDecorationConfig objects. Each config includes the active lines, style, optional underline color, thickness multiplier, underline offset, and skip-ink setting.

// Query the current decoration configurations
// Returns a list of unique TextDecorationConfig objects in the range
const decorations = engine.block.getTextDecorations(text);
// Each config contains: lines, style, underlineColor, underlineThickness, underlineOffset, skipInk

Custom Decoration Styles#

We set a specific decoration style using engine.block.setTextDecoration() with a TextDecorationConfig. Available styles are 'Solid' (default), 'Double', 'Dotted', 'Dashed', and 'Wavy'.

// Set a specific decoration style
// Available styles: 'Solid', 'Double', 'Dotted', 'Dashed', 'Wavy'
engine.block.setTextDecoration(text, {
  lines: ["Underline"],
  style: "Dashed",
});

Underline Color#

We set a custom underline color that differs from the text color. The underlineColor property only applies to underlines; strikethrough and overline always use the text color.

// Set a custom underline color (only applies to underlines)
// Strikethrough and overline always use the text color
engine.block.setTextDecoration(text, {
  lines: ["Underline"],
  underlineColor: { r: 1, g: 0, b: 0, a: 1 },
});

Decoration Thickness#

We adjust the underline thickness using the underlineThickness property. The default is 1.0. Values above 1.0 make the underline thicker.

// Adjust the underline thickness
// Default is 1.0, values above 1.0 make the line thicker
engine.block.setTextDecoration(text, {
  lines: ["Underline"],
  underlineThickness: 2.0,
});

Underline Offset#

We adjust the underline position using the underlineOffset property, which acts as a relative multiplier on the font-default distance. The actual position is computed as fontDefault * (1 + underlineOffset). The default is 0, which uses the font’s default underline position. Positive values move the underline proportionally further from the baseline, negative values move it proportionally closer.

// Adjust the underline position relative to the font default
// 0 = font default, positive values move further from baseline, negative values move closer
engine.block.setTextDecoration(text, {
  lines: ["Underline"],
  underlineOffset: 0.1,
});

Subrange Decorations#

We apply decorations to specific character ranges using UTF-16 indices [from, to). Both toggle and set operations accept range parameters.

// Apply decorations to a specific character range using UTF-16 indices
// Toggle underline on characters 0-5 ("Hello")
engine.block.toggleTextDecorationUnderline(text, 0, 5);

// Set strikethrough on characters 6-12 ("CE.SDK")
engine.block.setTextDecoration(text, { lines: ["Strikethrough"] }, 6, 12);

// Query decorations in a specific range
const subrangeDecorations = engine.block.getTextDecorations(text, 0, 5);

Combine Decorations#

We combine multiple decoration types by passing an array of lines to setTextDecoration(). All active lines share the same style and thickness.

// Combine multiple decoration lines on the same text
// All active lines share the same style and thickness
engine.block.setTextDecoration(text, {
  lines: ["Underline", "Strikethrough"],
  style: "Solid",
});

Remove Decorations#

We remove all decorations by setting the lines to ['None'].

// Remove all decorations
engine.block.setTextDecoration(text, { lines: ["None"] });

API Reference#

Method	Purpose
`engine.block.toggleTextDecorationUnderline()`	Toggle underline on entire text or range
`engine.block.toggleTextDecorationStrikethrough()`	Toggle strikethrough on entire text or range
`engine.block.toggleTextDecorationOverline()`	Toggle overline on entire text or range
`engine.block.getTextDecorations()`	Get ordered list of decoration configs in range
`engine.block.setTextDecoration()`	Set decoration config for entire text or range

Troubleshooting#

Decoration not visible: Ensure the text block has content and the decoration lines are not set to 'None'.

Underline color not changing: The underlineColor property only applies to underlines. Strikethrough and overline always use the text color.

Toggle not adding decoration: If all characters in the range already have the decoration, toggle removes it instead of adding it.
