Setup and Command-line Export

This guide walks you through exporting sample CreativeEditor SDK (CE.SDK) scenes on Linux using the CE.SDK Renderer Docker container.

5 mins
estimated time
GitHub

Who is This Guide For?#

This guide is for developers who:

  • Need to perform image exporting programmatically in a Linux server environment.
  • Want to use an NVIDIA GPU for accelerating the export time of CE.SDK scenes and archives.

What You’ll Achieve#

  • Install and configure Docker and the NVIDIA Container Runtime for Ubuntu Linux.
  • Fetch the CE.SDK Renderer container and learn how to configure scene exports.
  • Export designs as PNG images and MP4 videos on the server.

Prerequisites#

Before getting started, ensure you have a server or virtual machine running Ubuntu 24.04 LTS. The server should preferably have a GPU, image exports are possible but significantly slower without GPU acceleration. You can explore the full hardware requirements here .

Container variants#

We offer four container variants which are useful in different deployment scenarios: open-source and licensed codec variants, each having a variant that bundles our default assets and one that does not.

The demos provided use open-source codecs to get you up and running quickly, but these codecs do not come with patent license coverage which is required for legal AAC, H.264 and H.265 encoding and decoding. For production deployments, we offer licensed codec container variants, switching to them after your evaluation requires only authenticating with our private container registry and switching out the container image names in your deployment.

The other choice available to you is bundled assets vs assetless containers. cesdk-renderer containers that bundle the CDN assets in a local directory /opt/cesdk-renderer/assets, this allows for quicker exports as no CDN access is required, and gets you up and running quickly by having access to demo scenes for testing with simple commands. If you have customized your assets tree with custom sources and want to build your own version of the container, or you want to access them over http(s), we offer assetless container versions that only bundle the core assets required to run the renderer, saving about 300 MB in container size.

Step 1: Install the CE.SDK Renderer and see the available options#

To fetch the current version of the CE.SDK Renderer, use the following command:

Open-source codecs, bundled assets
Open-source codecs, assetless
Licensed codecs, bundled assets
Licensed codecs, assetless
Terminal window
sudo docker pull docker.io/imgly/cesdk-renderer:1.64.0

Then list the available command-line options by running the container with a --help flag:

Open-source codecs, bundled assets
Open-source codecs, assetless
Licensed codecs, bundled assets
Licensed codecs, assetless
Terminal window
sudo docker run docker.io/imgly/cesdk-renderer:1.64.0 --help

You should get a list of available options:

Renders a CE.SDK scene or archive to an image or video file.


Environment variables:
- CESDK_LICENSE - the license to unlock the engine (present)




./cesdk_cli [OPTIONS]




OPTIONS:
  -h,     --help              Print this help message and exit
  -i,     --input design.scene|archive.zip  REQUIRED
                              Input file name
  -o,     --output FILE|DIR   Output file name, automatically generated based on the scene type
                              if not provided. If only a directory is specified, the generated
                              output file is placed there, otherwise it defaults to the input
                              directory.
  -T,     --output-mime-type MIME
                              Manually specify a MIME type of the output instead of relying on
                              extension-based detection, e.g. image/png, video/mp4, etc.
  -v,     --verbose           Verbose output
  -j,     --json-progress     JSON progress output to stdout
  -b,     --base-path DIR|URL [/opt/cesdk-renderer/assets]
                              Assets root directory path. This can be an absolute file path, a
                              path relative to the current working directory, or a URL pointing
                              to an assets server.
[... advanced options listed here ...]

Step 2: Install the Docker and NVIDIA runtimes on the server#

For production use, you will need to have a working container runtime and the NVIDIA Container Toolkit on the target server.

If you can already run sudo docker run --rm --runtime=nvidia --gpus all ubuntu nvidia-smi in the context of your target server and successfuly get information about the host GPU, you can skip this step.

NVIDIA Container Toolkit setup on a bare metal server

This step closely follows the official NVIDIA guide for installing the Container Toolkit.

If you haven’t installed a compatible container engine yet, we recommend installing the Docker Engine first.

Run the following command to install the required packages and start the Docker daemon, you can skip the GPU runtime commands if only CPU rendering of images is needed:

Ubuntu / Debian
RHEL / CentOS / Fedora
OpenSUSE / SLE
Terminal window
# Install GPU video decoding drivers
sudo apt-get install -y vdpau-driver-all libvdpau-va-gl1


# Install the NVIDIA container runtime
curl -fsSL https://nvidia.github.io/libnvidia-container/gpgkey | sudo gpg --dearmor -o /usr/share/keyrings/nvidia-container-toolkit-keyring.gpg \
  && curl -s -L https://nvidia.github.io/libnvidia-container/stable/deb/nvidia-container-toolkit.list | \
    sed 's#deb https://#deb [signed-by=/usr/share/keyrings/nvidia-container-toolkit-keyring.gpg] https://#g' | \
    sudo tee /etc/apt/sources.list.d/nvidia-container-toolkit.list \
  && sudo apt-get update -y \
  && export NVIDIA_CONTAINER_TOOLKIT_VERSION=1.18.0-1 \
  && sudo apt-get install -y \
    nvidia-container-toolkit=${NVIDIA_CONTAINER_TOOLKIT_VERSION} \
    nvidia-container-toolkit-base=${NVIDIA_CONTAINER_TOOLKIT_VERSION} \
    libnvidia-container-tools=${NVIDIA_CONTAINER_TOOLKIT_VERSION} \
    libnvidia-container1=${NVIDIA_CONTAINER_TOOLKIT_VERSION}


# Configure the GPU runtime for the Docker daemon
sudo nvidia-ctk runtime configure --runtime=docker && sudo systemctl restart docker


# Test if the GPU runtime was properly configured and can see the GPU hardware
sudo docker run --rm --runtime=nvidia --gpus all ubuntu nvidia-smi

nvidia-smi run inside Docker should provide output similar to this:

+-----------------------------------------------------------------------------------------+
| NVIDIA-SMI 570.133.07             Driver Version: 570.133.07     CUDA Version: 12.8     |
|-----------------------------------------+------------------------+----------------------+
| GPU  Name                 Persistence-M | Bus-Id          Disp.A | Volatile Uncorr. ECC |
| Fan  Temp   Perf          Pwr:Usage/Cap |           Memory-Usage | GPU-Util  Compute M. |
|                                         |                        |               MIG M. |
|=========================================+========================+======================|
|   0  NVIDIA L4                      Off |   00000000:00:04.0 Off |                    0 |
| N/A   40C    P8             12W /   72W |       0MiB /  23034MiB |      0%      Default |
|                                         |                        |                  N/A |
+-----------------------------------------+------------------------+----------------------+


+-----------------------------------------------------------------------------------------+
| Processes:                                                                              |
|  GPU   GI   CI              PID   Type   Process name                        GPU Memory |
|        ID   ID                                                               Usage      |
|=========================================================================================|
|  No running processes found                                                             |
+-----------------------------------------------------------------------------------------+

The next steps assume that your current user is not part of the docker group for security reasons, if you did add it then you can skip the sudo before sudo docker invocations. However, this exposes you to the risk of enabling full root access from a regular user account, so we do not recommend doing it in production systems.

Step 3: Set up the project structure#

Create the following file and directory structure:

/my-processor-project
  ├── .env
  ├── demo.sh
  ├── input/
  ├── output/

Optional: .env (License key)#

If you already have a license key, put it in the .env file for later usage by the container. If you don’t, you can skip this step and you’ll get a watermarked output file.

Terminal window
CESDK_LICENSE=my.license.key

demo.sh#

The following shell script demonstrates how to directly run a one-off instance CE.SDK Renderer CLI via Docker:

Open-source codecs, bundled assets
Open-source codecs, assetless
Licensed codecs, bundled assets
Licensed codecs, assetless
#!/bin/bash
set -euo pipefail


# Load the license from the .env file if it exists (optional)
if [[ -f .env ]]; then
  . .env
fi


# Set the CESDK_RENDERER_VERSION to the latest version if not explicitly overridden
CESDK_RENDERER_VERSION=${CESDK_RENDERER_VERSION:-latest}


# Create the input and output directories if missing and set permissions
mkdir -p input output
chmod 0777 input output


# Run the renderer on one of the template scenes
# Add `--gpus all` to Docker arguments after `--rm` to use GPU rendering if an NVIDIA GPU is available.
docker run --rm -it \
    -e "CESDK_LICENSE=${CESDK_LICENSE:-}" \
    -v "$(pwd)/output:/output" -v "$(pwd)/input:/input" \
    "docker.io/imgly/cesdk-renderer:${CESDK_RENDERER_VERSION}" \
    --input "${INPUT_FILE:-/opt/cesdk-renderer/assets/demo/v2/ly.img.template/templates/cesdk_postcard_1.scene}" \
    --output "${OUTPUT_FILE:-/output/}"
    "$@"

Step 4: Run the Script#

Once everything is set up, run your script using:

Terminal window
./demo.sh

This will process the scene and generate an image file named output/postcard.jpg in your project directory:

A postcard with text "Layout, text and photo editing. All in one" on the left and a red-tinted photo of a woman on the right

If you have your own scene files to test, copy them into the input/ directory and export to various formats:

Terminal window
INPUT_FILE=/input/my-scene.scene OUTPUT_FILE=/output/my-scene.png ./demo.sh
INPUT_FILE=/input/my-scene.scene OUTPUT_FILE=/output/my-scene.jpg ./demo.sh
INPUT_FILE=/input/my-scene.scene OUTPUT_FILE=/output/my-scene.pdf ./demo.sh
INPUT_FILE=/input/my-archive.zip OUTPUT_FILE=/output/my-archive.png ./demo.sh
INPUT_FILE=/input/my-video.scene OUTPUT_FILE=/output/my-video.mp4 ./demo.sh

Expected Output#

When successful, you should see:

{"status":"loading","fractionComplete":0.0}
{"status":"exporting","fractionComplete":0.0}
{"status":"done","fractionComplete":1.0}

The --json-output flags will generate single-line JSON status reports periodically, these can be monitored on the process standard output to determine the progress of the export.

The default demo scene should output a output/postcard.jpg image.

Troubleshooting & Common Errors#

❌ Error encountered while creating an EGL hardware-accelerated context, falling back to CPU rendering: EGL initialize error: UNKNOWN

  • Make sure the GPU setup instructions were followed, this error indicates that a hardware OpenGL context could not be created inside the container.
  • This could also be expected if testing the container on a machine without a GPU.

❌ Error: Invalid license key

  • Verify that your license key is correct and not expired, or remove the key entirely to get watermarked output.

Next Steps#

Congratulations! You’ve successfully exported a scene with the CE.SDK Renderer using a simple shell script. Next, explore:
