Edit or Remove Assets - Next.js

Manage assets in local asset sources by updating metadata, removing individual assets, or deleting entire sources.

Edit or Remove Assets

10 mins

estimated time

Assets in local sources can be modified or removed after they have been added. CE.SDK provides two levels of removal: individual assets within a source and entire asset sources. This guide covers how to query, update, and remove assets programmatically, as well as how to notify the UI when changes occur.

import type { EditorPlugin, EditorPluginContext } from '@cesdk/cesdk-js';
import packageJson from './package.json';

class Example implements EditorPlugin {
  name = packageJson.name;

  version = packageJson.version;

  async initialize({ cesdk }: EditorPluginContext): Promise<void> {
    if (!cesdk) {
      throw new Error('CE.SDK instance is required for this plugin');
    }

    await cesdk.addDefaultAssetSources();
    await cesdk.addDemoAssetSources({
      sceneMode: 'Design',
      withUploadAssetSources: false
    });
    await cesdk.createDesignScene();

    const engine = cesdk.engine;

    // ===== Section 1: Create a Local Asset Source =====
    // Create a local asset source to manage images
    engine.asset.addLocalSource('my-uploads');

    // Add some sample assets to the source
    engine.asset.addAssetToSource('my-uploads', {
      id: 'image-1',
      label: { en: 'Mountain Landscape' },
      tags: { en: ['nature', 'mountain'] },
      meta: {
        uri: 'https://img.ly/static/ubq_samples/sample_1.jpg',
        thumbUri: 'https://img.ly/static/ubq_samples/sample_1.jpg',
        blockType: '//ly.img.ubq/graphic'
      }
    });

    engine.asset.addAssetToSource('my-uploads', {
      id: 'image-2',
      label: { en: 'Ocean Waves' },
      tags: { en: ['nature', 'water'] },
      meta: {
        uri: 'https://img.ly/static/ubq_samples/sample_2.jpg',
        thumbUri: 'https://img.ly/static/ubq_samples/sample_2.jpg',
        blockType: '//ly.img.ubq/graphic'
      }
    });

    engine.asset.addAssetToSource('my-uploads', {
      id: 'image-3',
      label: { en: 'Forest Path' },
      tags: { en: ['nature', 'forest'] },
      meta: {
        uri: 'https://img.ly/static/ubq_samples/sample_3.jpg',
        thumbUri: 'https://img.ly/static/ubq_samples/sample_3.jpg',
        blockType: '//ly.img.ubq/graphic'
      }
    });

    // ===== Section 2: Find Assets in a Source =====
    // Query assets from the source to find specific assets
    const result = await engine.asset.findAssets('my-uploads', {
      query: 'nature',
      page: 0,
      perPage: 100
    });

    console.log('Found assets:', result.assets.length);
    const assetToModify = result.assets.find((a) => a.id === 'image-1');
    console.log('Asset to modify:', assetToModify?.label);

    // ===== Section 3: Update Asset Metadata =====
    // To update an asset's metadata, remove it and add an updated version
    // This pattern ensures the asset library reflects the latest data
    engine.asset.removeAssetFromSource('my-uploads', 'image-1');

    // Add the updated version with new metadata
    engine.asset.addAssetToSource('my-uploads', {
      id: 'image-1',
      label: { en: 'Updated Mountain Photo' }, // New label
      tags: { en: ['nature', 'mountain', 'updated'] }, // New tags
      meta: {
        uri: 'https://img.ly/static/ubq_samples/sample_1.jpg',
        thumbUri: 'https://img.ly/static/ubq_samples/sample_1.jpg',
        blockType: '//ly.img.ubq/graphic'
      }
    });

    // ===== Section 4: Remove an Asset from a Source =====
    // Remove a single asset from the source
    // Blocks already using this asset on the canvas remain unaffected
    engine.asset.removeAssetFromSource('my-uploads', 'image-2');
    console.log('Removed image-2 from my-uploads');

    // ===== Section 5: Notify UI of Changes =====
    // After modifying assets, notify the UI to refresh
    // This triggers update events for components like the asset library panel
    engine.asset.assetSourceContentsChanged('my-uploads');

    // ===== Section 6: Create a Second Source for Removal Demo =====
    // Create a temporary source to demonstrate source removal
    engine.asset.addLocalSource('temporary-uploads');

    engine.asset.addAssetToSource('temporary-uploads', {
      id: 'temp-1',
      label: { en: 'Temporary Image' },
      meta: {
        uri: 'https://img.ly/static/ubq_samples/sample_4.jpg',
        thumbUri: 'https://img.ly/static/ubq_samples/sample_4.jpg',
        blockType: '//ly.img.ubq/graphic'
      }
    });

    // ===== Section 7: Remove an Entire Asset Source =====
    // Remove a complete asset source and all its assets
    // Any UI panels displaying this source will stop showing content
    engine.asset.removeSource('temporary-uploads');
    console.log('Removed temporary-uploads source');

    // ===== Section 8: Listen to Asset Source Events =====
    // Subscribe to lifecycle events for asset sources
    const unsubscribeAdded = engine.asset.onAssetSourceAdded((sourceId) => {
      console.log(`Source added: ${sourceId}`);
    });

    const unsubscribeRemoved = engine.asset.onAssetSourceRemoved((sourceId) => {
      console.log(`Source removed: ${sourceId}`);
    });

    const unsubscribeUpdated = engine.asset.onAssetSourceUpdated((sourceId) => {
      console.log(`Source updated: ${sourceId}`);
    });

    // Demonstrate events by creating and removing a source
    engine.asset.addLocalSource('event-demo-source');
    engine.asset.assetSourceContentsChanged('event-demo-source');
    engine.asset.removeSource('event-demo-source');

    // Clean up subscriptions when no longer needed
    unsubscribeAdded();
    unsubscribeRemoved();
    unsubscribeUpdated();

    // ===== Configure Asset Library Display =====
    // Configure the asset library to show our custom source
    cesdk.ui.updateAssetLibraryEntry('ly.img.image', {
      sourceIds: ['my-uploads'],
      gridBackgroundType: 'cover',
      previewBackgroundType: 'contain'
    });

    // Open the asset library to show the custom uploads
    cesdk.ui.openPanel('//ly.img.panel/assetLibrary', {
      payload: {
        entries: ['ly.img.image']
      }
    });
  }
}

export default Example;

Setup#

Initialize CE.SDK and create a local asset source with sample assets. The example creates a design scene and populates a local source with images.

await cesdk.addDefaultAssetSources();
await cesdk.addDemoAssetSources({
  sceneMode: 'Design',
  withUploadAssetSources: false
});
await cesdk.createDesignScene();

const engine = cesdk.engine;

Creating a Local Asset Source#

Before editing or removing assets, you need a local source with assets. Use engine.asset.addLocalSource() to create a source, then engine.asset.addAssetToSource() to populate it.

// Create a local asset source to manage images
engine.asset.addLocalSource('my-uploads');

// Add some sample assets to the source
engine.asset.addAssetToSource('my-uploads', {
  id: 'image-1',
  label: { en: 'Mountain Landscape' },
  tags: { en: ['nature', 'mountain'] },
  meta: {
    uri: 'https://img.ly/static/ubq_samples/sample_1.jpg',
    thumbUri: 'https://img.ly/static/ubq_samples/sample_1.jpg',
    blockType: '//ly.img.ubq/graphic'
  }
});

engine.asset.addAssetToSource('my-uploads', {
  id: 'image-2',
  label: { en: 'Ocean Waves' },
  tags: { en: ['nature', 'water'] },
  meta: {
    uri: 'https://img.ly/static/ubq_samples/sample_2.jpg',
    thumbUri: 'https://img.ly/static/ubq_samples/sample_2.jpg',
    blockType: '//ly.img.ubq/graphic'
  }
});

engine.asset.addAssetToSource('my-uploads', {
  id: 'image-3',
  label: { en: 'Forest Path' },
  tags: { en: ['nature', 'forest'] },
  meta: {
    uri: 'https://img.ly/static/ubq_samples/sample_3.jpg',
    thumbUri: 'https://img.ly/static/ubq_samples/sample_3.jpg',
    blockType: '//ly.img.ubq/graphic'
  }
});

Each asset has a unique id, descriptive label and tags for searchability, and meta properties including the uri for the asset file.

Finding Assets in a Source#

Use engine.asset.findAssets() to query assets from a source. You can search by query string to match labels and tags, and paginate results for large sources.

// Query assets from the source to find specific assets
const result = await engine.asset.findAssets('my-uploads', {
  query: 'nature',
  page: 0,
  perPage: 100
});

console.log('Found assets:', result.assets.length);
const assetToModify = result.assets.find((a) => a.id === 'image-1');
console.log('Asset to modify:', assetToModify?.label);

The findAssets() method returns an object containing the assets array, total count, currentPage, and optionally nextPage for pagination.

Updating Asset Metadata#

CE.SDK does not provide a direct update method for assets. To modify an asset’s metadata (labels, tags, URIs), remove the existing asset and add an updated version with the same ID.

// To update an asset's metadata, remove it and add an updated version
// This pattern ensures the asset library reflects the latest data
engine.asset.removeAssetFromSource('my-uploads', 'image-1');

// Add the updated version with new metadata
engine.asset.addAssetToSource('my-uploads', {
  id: 'image-1',
  label: { en: 'Updated Mountain Photo' }, // New label
  tags: { en: ['nature', 'mountain', 'updated'] }, // New tags
  meta: {
    uri: 'https://img.ly/static/ubq_samples/sample_1.jpg',
    thumbUri: 'https://img.ly/static/ubq_samples/sample_1.jpg',
    blockType: '//ly.img.ubq/graphic'
  }
});

This pattern ensures the asset library reflects the latest metadata. The asset ID remains the same, so any references to the asset continue to work.

Removing an Asset from a Source#

Remove individual assets using engine.asset.removeAssetFromSource(). The asset is permanently deleted from the source, but blocks already using that asset on the canvas remain unaffected.

// Remove a single asset from the source
// Blocks already using this asset on the canvas remain unaffected
engine.asset.removeAssetFromSource('my-uploads', 'image-2');
console.log('Removed image-2 from my-uploads');

Removing an asset only affects the asset library—it does not modify or delete any blocks that were created using that asset.

Notifying the UI of Changes#

After modifying assets in a source, call engine.asset.assetSourceContentsChanged() to notify UI components. This triggers update events for the asset library panel and any other components displaying the source.

// After modifying assets, notify the UI to refresh
// This triggers update events for components like the asset library panel
engine.asset.assetSourceContentsChanged('my-uploads');

Without this notification, UI components may show stale data until the user navigates away and returns.

Creating a Temporary Source#

You can create additional sources for temporary or session-specific assets. These sources can be removed entirely when no longer needed.

// Create a temporary source to demonstrate source removal
engine.asset.addLocalSource('temporary-uploads');

engine.asset.addAssetToSource('temporary-uploads', {
  id: 'temp-1',
  label: { en: 'Temporary Image' },
  meta: {
    uri: 'https://img.ly/static/ubq_samples/sample_4.jpg',
    thumbUri: 'https://img.ly/static/ubq_samples/sample_4.jpg',
    blockType: '//ly.img.ubq/graphic'
  }
});

Removing an Entire Asset Source#

Remove a complete asset source and all its assets using engine.asset.removeSource(). Any UI panels displaying this source will stop showing content for that source.

// Remove a complete asset source and all its assets
// Any UI panels displaying this source will stop showing content
engine.asset.removeSource('temporary-uploads');
console.log('Removed temporary-uploads source');

Use this when cleaning up temporary sources or when a user explicitly deletes an entire category of assets.

Listening to Asset Source Events#

Subscribe to lifecycle events to react when sources are added, removed, or updated. These events are useful for analytics, cleanup tasks, or syncing with external systems.

// Subscribe to lifecycle events for asset sources
const unsubscribeAdded = engine.asset.onAssetSourceAdded((sourceId) => {
  console.log(`Source added: ${sourceId}`);
});

const unsubscribeRemoved = engine.asset.onAssetSourceRemoved((sourceId) => {
  console.log(`Source removed: ${sourceId}`);
});

const unsubscribeUpdated = engine.asset.onAssetSourceUpdated((sourceId) => {
  console.log(`Source updated: ${sourceId}`);
});

// Demonstrate events by creating and removing a source
engine.asset.addLocalSource('event-demo-source');
engine.asset.assetSourceContentsChanged('event-demo-source');
engine.asset.removeSource('event-demo-source');

// Clean up subscriptions when no longer needed
unsubscribeAdded();
unsubscribeRemoved();
unsubscribeUpdated();

Each subscription returns an unsubscribe function. Call it when you no longer need to receive events to prevent memory leaks.

Best Practices#

Query before modifying: Use findAssets() to verify the asset exists before attempting removal
Notify UI after changes: Always call assetSourceContentsChanged() after modifying a source
Clean up subscriptions: Store unsubscribe functions and call them when the component unmounts or the source is removed
Handle missing assets gracefully: Check if findAssets() returns the expected asset before operating on it
Use descriptive IDs: Choose asset IDs that are unique and meaningful for easier debugging

Troubleshooting#

Issue	Cause	Solution
Asset not found	ID mismatch or asset already removed	Use `findAssets()` to list available assets
UI not updating	Missing notification	Call `assetSourceContentsChanged()` after modifications
Cannot remove asset	Source is not a local source	Only local sources support `removeAssetFromSource()`
Events not firing	Subscription not active	Verify the subscription was created before the operation

API Reference#

Method	Category	Purpose
`engine.asset.findAssets()`	Asset Discovery	Query assets from a source with filtering and pagination
`engine.asset.addAssetToSource()`	Asset Lifecycle	Add or update an asset in a local source
`engine.asset.removeAssetFromSource()`	Asset Lifecycle	Remove a single asset from a local source
`engine.asset.removeSource()`	Source Management	Remove an entire asset source and all its assets
`engine.asset.assetSourceContentsChanged()`	UI Notification	Notify UI that source contents changed
`engine.asset.onAssetSourceAdded()`	Event Subscriptions	Subscribe to source addition events
`engine.asset.onAssetSourceRemoved()`	Event Subscriptions	Subscribe to source removal events
`engine.asset.onAssetSourceUpdated()`	Event Subscriptions	Subscribe to source content change events
