Register a New Component

Register custom UI components using CE.SDK’s builder system and place them in different areas of the editor interface like the navigation bar, inspector bar, dock, and canvas menu.

10 mins

estimated time

Download

StackBlitz

GitHub

The builder system provides a declarative API for creating UI components that integrate with CE.SDK. Components registered via cesdk.ui.registerComponent() receive a render function that is automatically re-invoked when relevant engine state changes, enabling reactive UIs without manual subscription management. You can create buttons, dropdowns, inputs, and other UI elements that react to engine state changes.

import type { EditorPlugin, EditorPluginContext } from '@cesdk/cesdk-js';

const registerNewComponentPlugin: EditorPlugin = {
  name: 'ly.img.registerNewComponentPlugin',
  version: '1.0.0',

  async initialize({ cesdk, engine }: EditorPluginContext) {
    if (cesdk == null) return;

    // Load a scene so the editor has content to display
    await engine.scene.loadFromURL(
      'https://cdn.img.ly/assets/demo/v3/ly.img.template/templates/cesdk_postcard_1.scene'
    );

    // Register a custom button component that shows the selected block's type.
    // The render function is automatically re-invoked when engine state changes.
    cesdk.ui.registerComponent(
      'com.example.blockTypeButton',
      ({ builder, engine: eng, cesdk: cesdkInstance }) => {
        // Engine API calls are tracked. When the selection changes,
        // the component re-renders automatically.
        const selectedBlocks = eng.block.findAllSelected();
        const selectedBlock =
          selectedBlocks.length > 0 ? selectedBlocks[0] : null;
        const blockType = selectedBlock
          ? eng.block.getType(selectedBlock)
          : null;
        const label = blockType ? formatBlockType(blockType) : 'No Selection';

        builder.Button('block-type-display', {
          label,
          icon: '@imgly/icons/Info',
          isDisabled: !selectedBlock,
          onClick: () => {
            const message = selectedBlock
              ? `Selected block type: ${blockType}`
              : 'No block selected';
            cesdkInstance.ui.showNotification({ message, type: 'info' });
          }
        });
      }
    );

    // Register a component with a dropdown menu containing buttons.
    // Dropdowns in the navigation bar support Button and Separator elements.
    cesdk.ui.registerComponent(
      'com.example.actionsDropdown',
      ({ builder, engine: eng, cesdk: cesdkInstance }) => {
        const selectedBlocks = eng.block.findAllSelected();
        const selectedBlock =
          selectedBlocks.length > 0 ? selectedBlocks[0] : null;

        builder.Dropdown('actions-dropdown', {
          label: 'Actions',
          icon: '@imgly/icons/Adjustments',
          children: () => {
            builder.Button('action-duplicate', {
              label: 'Duplicate',
              icon: '@imgly/icons/Duplicate',
              variant: 'plain',
              isDisabled: !selectedBlock,
              onClick: () => {
                if (selectedBlock) {
                  eng.block.duplicate(selectedBlock);
                  cesdkInstance.ui.showNotification({
                    message: 'Block duplicated',
                    type: 'info'
                  });
                }
              }
            });

            builder.Button('action-delete', {
              label: 'Delete',
              icon: '@imgly/icons/Trash',
              variant: 'plain',
              color: 'danger',
              isDisabled: !selectedBlock,
              onClick: () => {
                if (selectedBlock) {
                  eng.block.destroy(selectedBlock);
                  cesdkInstance.ui.showNotification({
                    message: 'Block deleted',
                    type: 'info'
                  });
                }
              }
            });

            builder.Separator('action-separator');

            builder.Button('action-select-all', {
              label: 'Select All',
              icon: '@imgly/icons/SelectAll',
              variant: 'plain',
              onClick: () => {
                const page = eng.scene.getCurrentPage();
                if (page) {
                  const children = eng.block.getChildren(page);
                  children.forEach((child) =>
                    eng.block.setSelected(child, true)
                  );
                }
              }
            });
          }
        });
      }
    );

    // Place the custom components in the navigation bar.
    // Use setNavigationBarOrder to define the order of components.
    cesdk.ui.setNavigationBarOrder([
      'ly.img.save',
      'com.example.blockTypeButton',
      'com.example.actionsDropdown',
      'ly.img.spacer',
      'ly.img.undo',
      'ly.img.redo',
      'ly.img.zoom.navigationBar'
    ]);
  }
};

// Helper function to format block type for display
function formatBlockType(blockType: string): string {
  // Extract the last part of the block type (e.g., '//ly.img.ubq/graphic' -> 'Graphic')
  const parts = blockType.split('/');
  const typeName = parts[parts.length - 1];
  return typeName.charAt(0).toUpperCase() + typeName.slice(1);
}

export default registerNewComponentPlugin;

This guide demonstrates registering custom components including a button, dropdown menu, checkbox, and select control, then placing them in the navigation bar and inspector bar.

Registering a Component#

Use cesdk.ui.registerComponent() to register a component with a unique ID and a render function. The render function receives builder, engine, cesdk, state, and payload parameters.

// Register a custom button component that shows the selected block's type.
// The render function is automatically re-invoked when engine state changes.
cesdk.ui.registerComponent(
  'com.example.blockTypeButton',
  ({ builder, engine: eng, cesdk: cesdkInstance }) => {
    // Engine API calls are tracked. When the selection changes,
    // the component re-renders automatically.
    const selectedBlocks = eng.block.findAllSelected();
    const selectedBlock =
      selectedBlocks.length > 0 ? selectedBlocks[0] : null;
    const blockType = selectedBlock
      ? eng.block.getType(selectedBlock)
      : null;
    const label = blockType ? formatBlockType(blockType) : 'No Selection';

    builder.Button('block-type-display', {
      label,
      icon: '@imgly/icons/Info',
      isDisabled: !selectedBlock,
      onClick: () => {
        const message = selectedBlock
          ? `Selected block type: ${blockType}`
          : 'No block selected';
        cesdkInstance.ui.showNotification({ message, type: 'info' });
      }
    });
  }
);

Component ID Naming#

Use reverse domain notation for component IDs (e.g., 'com.example.myButton'). This ensures uniqueness and avoids conflicts with built-in components.

Render Function Signature#

The render function receives these parameters:

builder: Object providing methods to create UI elements
engine: The engine instance for accessing block and scene state
cesdk: The editor instance for UI operations like notifications
state: Function for managing local component state
payload: Optional data passed when adding the component to an order

Engine Reactivity#

Components automatically re-render when engine APIs called within the render function detect state changes. Engine method calls like engine.block.findAllSelected() are tracked, and only components that use changed engine state re-render.

In the example above, calling eng.block.findAllSelected() and eng.block.getType() inside the render function creates automatic subscriptions. When the selection changes, the component re-renders with updated values.

This reactive approach eliminates manual subscription management. The builder system handles all subscriptions internally.

Using Builder Elements#

The builder object provides methods to create UI elements within your component.

Button#

The builder.Button() method creates an interactive button. It accepts a unique ID and configuration options including label, icon, onClick, and state flags like isDisabled.

Use builder.Dropdown() to create a dropdown menu with nested content. The children callback function lets you add buttons and separators inside the dropdown.

// Register a component with a dropdown menu containing buttons.
// Dropdowns in the navigation bar support Button and Separator elements.
cesdk.ui.registerComponent(
  'com.example.actionsDropdown',
  ({ builder, engine: eng, cesdk: cesdkInstance }) => {
    const selectedBlocks = eng.block.findAllSelected();
    const selectedBlock =
      selectedBlocks.length > 0 ? selectedBlocks[0] : null;

    builder.Dropdown('actions-dropdown', {
      label: 'Actions',
      icon: '@imgly/icons/Adjustments',
      children: () => {
        builder.Button('action-duplicate', {
          label: 'Duplicate',
          icon: '@imgly/icons/Duplicate',
          variant: 'plain',
          isDisabled: !selectedBlock,
          onClick: () => {
            if (selectedBlock) {
              eng.block.duplicate(selectedBlock);
              cesdkInstance.ui.showNotification({
                message: 'Block duplicated',
                type: 'info'
              });
            }
          }
        });

        builder.Button('action-delete', {
          label: 'Delete',
          icon: '@imgly/icons/Trash',
          variant: 'plain',
          color: 'danger',
          isDisabled: !selectedBlock,
          onClick: () => {
            if (selectedBlock) {
              eng.block.destroy(selectedBlock);
              cesdkInstance.ui.showNotification({
                message: 'Block deleted',
                type: 'info'
              });
            }
          }
        });

        builder.Separator('action-separator');

        builder.Button('action-select-all', {
          label: 'Select All',
          icon: '@imgly/icons/SelectAll',
          variant: 'plain',
          onClick: () => {
            const page = eng.scene.getCurrentPage();
            if (page) {
              const children = eng.block.getChildren(page);
              children.forEach((child) =>
                eng.block.setSelected(child, true)
              );
            }
          }
        });
      }
    });
  }
);

The dropdown receives the same configuration as buttons, but uses children instead of onClick to define the dropdown content.

Available Builder Components#

Not every location supports every builder component yet. The following table shows the available builder components and their properties.

Builder Component	Description	Properties
`builder.Button`	A simple button to react on a user click.	label: The button label (supports i18n keys). onClick: Click handler. variant: `regular` (default) or `plain`. color: `accent` or `danger`. icon: The button icon. trailingIcon: Trailing icon. isActive: Active state indicator. isSelected: Selected state indicator. isDisabled: Disabled state. isLoading: Loading state. loadingProgress: Progress value 0-1. tooltip: Hover tooltip (supports i18n keys).
`builder.ButtonGroup`	Grouping of multiple buttons in a segmented control.	children: Function to render grouped buttons (only Button and Dropdown allowed).
`builder.Dropdown`	A button that opens a dropdown with content.	Same as Button, but with children instead of onClick for dropdown content.
`builder.Heading`	Renders text as a heading.	content: The heading text.
`builder.Separator`	Adds visual separation between entries.	No properties. Follows special layout rules for consecutive separators.
`builder.Component`	Renders another registered component.	componentId: The registered component ID. payload: Optional data passed to the component.
`builder.Checkbox`	Toggle checkbox control.	value: Current value. setValue: Change handler. inputLabel: Checkbox label.
`builder.Select`	Dropdown select with options.	value: Current selection object. setValue: Change handler. values: Array of option objects with `id`, `label`, and optional `icon`.
`builder.TextInput`	Text input field.	value: Current value. setValue: Change handler. placeholder: Placeholder text.
`builder.NumberInput`	Numeric input field.	value: Current value. setValue: Change handler. min/max: Range limits.
`builder.Slider`	Numeric range slider.	value: Current value. setValue: Change handler. min/max/step: Range configuration.
`builder.Section`	Container for grouping related controls.	children: Function to render section contents.

Managing Component State#

The state function provides local state management within components, similar to React’s useState.

const { value, setValue } = state('unique-id', defaultValue);

State persists across re-renders with the same ID. Calling setValue() triggers a component re-render. Since the returned object matches input component expectations, you can spread it directly into components.

cesdk.ui.registerComponent('counter', ({ builder, state }) => {
  const { value, setValue } = state('counter', 0);

  builder.Button('counter-button', {
    label: `${value} clicks`,
    onClick: () => {
      setValue(value + 1);
    }
  });
});

Add components to the navigation bar using cesdk.ui.setNavigationBarOrder(). The navigation bar appears at the top of the editor.

// Place the custom components in the navigation bar.
// Use setNavigationBarOrder to define the order of components.
cesdk.ui.setNavigationBarOrder([
  'ly.img.save',
  'com.example.blockTypeButton',
  'com.example.actionsDropdown',
  'ly.img.spacer',
  'ly.img.undo',
  'ly.img.redo',
  'ly.img.zoom.navigationBar'
]);

Use cesdk.ui.insertNavigationBarOrderComponent() to position components relative to existing ones without replacing the entire order.

Placing Components in the Inspector Bar#

The inspector bar appears at the bottom when a block is selected. Add components using cesdk.ui.setInspectorBarOrder() or position relative to existing components with cesdk.ui.insertInspectorBarOrderComponent().

cesdk.ui.setInspectorBarOrder([
  'com.example.myInspectorButton',
  'ly.img.fill',
  'ly.img.stroke'
]);

Placing Components in the Dock#

The dock is the vertical sidebar for asset libraries and tools. Add components using cesdk.ui.setDockOrder() or cesdk.ui.insertDockOrderComponent().

cesdk.ui.insertDockOrderComponent(
  { id: 'ly.img.assetLibrary.dock' },
  'com.example.myDockButton',
  'after'
);

The canvas menu appears as a floating menu near selected blocks. Add components using cesdk.ui.setCanvasMenuOrder() or cesdk.ui.insertCanvasMenuOrderComponent().

cesdk.ui.setCanvasMenuOrder([
  'ly.img.delete',
  'com.example.myCanvasMenuAction',
  'ly.img.duplicate'
]);

Placing Components in the Canvas Bar#

Canvas bars appear above or below the canvas area. Specify 'top' or 'bottom' position using cesdk.ui.setCanvasBarOrder() or cesdk.ui.insertCanvasBarOrderComponent().

cesdk.ui.setCanvasBarOrder(['com.example.myCanvasBarButton'], 'top');

Passing Payload Data#

Components can receive contextual data through the payload parameter. Pass data when adding a component to an order using an object with id and additional properties.

cesdk.ui.registerComponent(
  'myDockEntry.dock',
  ({ builder: { Button }, payload }) => {
    const { label } = payload;
    Button('entry-button', { label });
  }
);

cesdk.ui.setDockOrder([
  {
    id: 'myDockEntry.dock',
    label: 'Custom Label'
  }
]);

Use TypeScript generics with registerComponent<PayloadType>() to type the payload parameter.

Troubleshooting#

Component Not Rendering#

Verify the component ID matches between registration and placement in order arrays. Check that the registration happens before setting the order. Component IDs are case-sensitive.

State Not Persisting#

Ensure unique state IDs within the component. Duplicate IDs cause conflicts and unexpected behavior. Each state() call should use a distinct identifier.

Component Not Updating#

Confirm engine API calls are made inside the render function, not outside. The reactor only tracks calls made during the render function execution. Moving engine calls outside breaks reactivity.

Order Changes Not Applying#

Check that the order method matches the UI location. Use setDockOrder() for the dock, setNavigationBarOrder() for navigation, and so on. Mismatched methods silently fail.

API Reference#

Method	Category	Purpose
`cesdk.ui.registerComponent()`	Component Registration	Register a custom component with a unique ID and render function
`cesdk.ui.setNavigationBarOrder()`	UI Layout	Set the order of components in the navigation bar
`cesdk.ui.getNavigationBarOrder()`	UI Layout	Get the current navigation bar component order
`cesdk.ui.insertNavigationBarOrderComponent()`	UI Layout	Insert a component relative to an existing navigation bar component
`cesdk.ui.setInspectorBarOrder()`	UI Layout	Set the order of components in the inspector bar
`cesdk.ui.getInspectorBarOrder()`	UI Layout	Get the current inspector bar component order
`cesdk.ui.insertInspectorBarOrderComponent()`	UI Layout	Insert a component relative to an existing inspector bar component
`cesdk.ui.setDockOrder()`	UI Layout	Set the order of components in the dock
`cesdk.ui.getDockOrder()`	UI Layout	Get the current dock component order
`cesdk.ui.insertDockOrderComponent()`	UI Layout	Insert a component relative to an existing dock component
`cesdk.ui.setCanvasMenuOrder()`	UI Layout	Set the order of components in the canvas menu
`cesdk.ui.getCanvasMenuOrder()`	UI Layout	Get the current canvas menu component order
`cesdk.ui.insertCanvasMenuOrderComponent()`	UI Layout	Insert a component relative to an existing canvas menu component
`cesdk.ui.setCanvasBarOrder()`	UI Layout	Set the order of components in the canvas bar (top or bottom)
`cesdk.ui.getCanvasBarOrder()`	UI Layout	Get the current canvas bar component order
`cesdk.ui.insertCanvasBarOrderComponent()`	UI Layout	Insert a component relative to an existing canvas bar component
`builder.Button()`	Builder	Create an interactive button element
`builder.Dropdown()`	Builder	Create a dropdown menu with nested children
`builder.ButtonGroup()`	Builder	Create a group of related buttons
`builder.Checkbox()`	Builder	Create a toggle checkbox control
`builder.Select()`	Builder	Create a select dropdown with predefined options
`builder.TextInput()`	Builder	Create a text input field
`builder.NumberInput()`	Builder	Create a numeric input field
`builder.Slider()`	Builder	Create a numeric slider control
`builder.Section()`	Builder	Create a container for grouping controls
`builder.Separator()`	Builder	Create a visual divider
`builder.Heading()`	Builder	Create a heading text element
`builder.Component()`	Builder	Render another registered component with optional payload
`state()`	Component State	Access local state with get/set capabilities

Registering a Component#

Component ID Naming#

Render Function Signature#

Engine Reactivity#

Using Builder Elements#

Button#

Available Builder Components#

Managing Component State#

Placing Components in the Navigation Bar#

Placing Components in the Inspector Bar#

Placing Components in the Dock#

Placing Components in the Canvas Menu#

Placing Components in the Canvas Bar#

Passing Payload Data#

Troubleshooting#

Component Not Rendering#

State Not Persisting#

Component Not Updating#

Order Changes Not Applying#

API Reference#

Register a New Component

Registering a Component#

Component ID Naming#

Render Function Signature#

Engine Reactivity#

Using Builder Elements#

Button#

Dropdown with Nested Content#

Available Builder Components#

Managing Component State#

Placing Components in the Navigation Bar#

Placing Components in the Inspector Bar#

Placing Components in the Dock#

Placing Components in the Canvas Menu#

Placing Components in the Canvas Bar#

Passing Payload Data#

Troubleshooting#

Component Not Rendering#

State Not Persisting#

Component Not Updating#

Order Changes Not Applying#

API Reference#
