Create From Image

Create an editable scene from an image with the Android Engine API. The engine builds a single-page scene sized to the image and configured in pixel design units, ready for immediate editing.

A photograph loaded as an editable Android Engine scene, with the page sized to and filled by the source image.

5 mins
estimated time
GitHub

engine.scene.createFromImage() loads the image, creates a scene whose page matches the image dimensions, and adds the image directly as the page fill. Use this when an image file is the starting point for an editing workflow where users enhance, annotate, or transform the image.

Create a Scene From an Image URL#

Pass a remote or local image Uri to createFromImage(). The suspend function returns after the image is loaded and the scene is ready for editing.

val imageRemoteUri = Uri.parse("https://img.ly/static/ubq_samples/sample_4.jpg")
engine.scene.createFromImage(imageRemoteUri)

The scene’s page dimensions match the image, and the scene uses pixel design units.

Inspect the Page Fill#

The image becomes the page’s fill rather than a separate image block. Locate the page with findByType() and read its dimensions when you need to position additional blocks relative to the image.

val page = engine.block.findByType(DesignBlockType.Page).first()
val pageWidth = engine.block.getWidth(page)
val pageHeight = engine.block.getHeight(page)

Read the page fill and compare its type with FillType.Image to confirm that the image is attached to the page.

val pageFill = engine.block.getFill(page)
val imageFillType = engine.block.getType(pageFill)

Create a Scene From Image Bytes#

When the image arrives as raw bytes from a file picker, network response, or other app storage, write those bytes to a file that remains available to the engine. This sample fetches the bytes from a URL to stand in for data your app already holds.

val blobUrl = URL("https://img.ly/static/ubq_samples/sample_4.jpg")
val imageBytes = withContext(Dispatchers.IO) {
    val outputStream = ByteArrayOutputStream()
    blobUrl.openStream().use { inputStream ->
        outputStream.use(inputStream::copyTo)
    }
    outputStream.toByteArray()
}

Write the bytes to a temporary image file and create a Uri for that file.

val blobFile = withContext(Dispatchers.IO) {
    File.createTempFile("cesdk-image-", ".jpg").apply {
        outputStream().use { it.write(imageBytes) }
    }
}
val blobUri = Uri.fromFile(blobFile)

Use the file Uri as the image source for createFromImage().

engine.scene.createFromImage(blobUri)

As with a remote URL, the created page matches the source image dimensions and uses an image fill.

val page = engine.block.findByType(DesignBlockType.Page).first()
val pageWidth = engine.block.getWidth(page)
val pageHeight = engine.block.getHeight(page)
val pageFill = engine.block.getFill(page)
val imageFillType = engine.block.getType(pageFill)

Configure Scene Parameters#

createFromImage() accepts optional parameters that control how the image maps to scene dimensions and how pages are arranged.

val configuredScene = engine.scene.createFromImage(
    imageUri = imageRemoteUri,
    dpi = 300F,
    pixelScaleFactor = 1F,
    sceneLayout = SceneLayout.FREE,
)
Parameter Default Description
dpi 300F Dots per inch of the scene, used when converting between pixels and physical units.
pixelScaleFactor 1F Scale factor applied to the final export resolution.
sceneLayout SceneLayout.FREE Page arrangement: FREE, HORIZONTAL_STACK, VERTICAL_STACK, or DEPTH_STACK.

To later save your scene, see Saving Scenes.

API Reference#

Method Description
engine.scene.createFromImage(imageUri=_) Create a scene whose single page is sized to the image and filled with it
engine.scene.createFromImage(imageUri=_, dpi=_, pixelScaleFactor=_, sceneLayout=_) Create an image scene with explicit DPI, scale, and layout parameters
engine.block.findByType(type=DesignBlockType.Page) Find page blocks in the current scene
engine.block.getWidth(block=_) Read the page width
engine.block.getHeight(block=_) Read the page height
engine.block.getFill(block=_) Get the fill block attached to a page
engine.block.getType(block=_) Read a block type string, including the fill type
Uri.parse(_) Create a Uri from a remote or local string
Uri.fromFile(_) Create a Uri from a local file
URL.openStream() Read image bytes from a remote URL
File.createTempFile(prefix=_, suffix=_) Create a temporary file for image bytes
engine.scene.saveToString(scene=_) Save the scene as a string
engine.scene.saveToArchive(scene=_) Save the scene with embedded assets
